FOCBOX UNITY (GENUINE)

Regular price $199 Unit price  per

Shipping calculated at checkout.

SHIPPING TIMES FOR FOXBOX UNITY ARE IMPROVED NOW.
ALSO YOU MAY CHOOSE EXPEDITED OPTION FOR VERY FAST DELIVERY OF FOCBOX

ORIGINAL FOCBOX UNITY



If you want to build a high-quality electric skateboard with high-performance reliability. FOCBOX is latest & best technology currently available. Focbox is based upon the VESC Open Source Project NOTE: This is a DIY product for building your own electric skateboard, some prior technical knowledge is required to successfully configure this product to function correctly.

  • Powerful start torque on sensorless motors
  • Built-in High Power Switch
  • Impact Resistant Silicone & Alloy Case
  • Bluetooth Connectivity
  • Up to 160A Continuous System Current

FOCBOX UNITY SPECIFICATIONS

Features & Benefits

Built-in High Power Switch

Smart power down

Roll to start

Impact Resistant Silicone & Alloy Case

Dual aluminium heatsink

5V 1A Output for external devices

Bluetooth Connectivity

Regenerative braking charges battery

Sensored & Sensorless Motor Control

Powerful start torque on sensorless motors

Robust USB C interface

Performance Specifications

160A Continuous System Current

80A Continuous Motor Current

300A Max Current

Voltage rating of components 8V-50V

Compatible battery 3S to 12S

FOC Control for quiet operation

NEW: Android Application

Ultra fast setup wizard

Automatic Motor direction detection

Simple battery configuration

Motor power optimization algorithm

Custom User profiles

Error detection



Software Features

Advanced configuration suite

Adjustable Motor & Battery Current Limits

Low & High Voltage limits

Regenerative Battery Current Control

Advanced Features

Battery Protection System Built-in

Over Voltage protection

Current and voltage monitoring on all phases

Field Oriented Control

Rapid duty cycle changes

High RPM & RPM Limits (bi-directional)

Soft backoff for over current & over temp

amp-hour and watt-hour counting

Firmware & GUI

Open Source by Ben Vedder

Source Files

ChibiOS/RT

GUI Built with QT





Dimensions

Main PCB: 113mm x 63mm

Outer Case Footprint: 117mm x 64mm

Outer Case Height: 19mm

Motor Wires: 50mm

Power Wire & Plug: 40mm

Mounting Hole pattern: 15mm X 30mm

Control Interface

PPM, Analog, UART, USB C,

CAN-bus, I2C
